Blizzard SkyBox 5 LED RGBAW Par Fixture w/Rechargeable Battery & Wireless DMX

(0)No Reviews yet
$549.99
SKU: Blizzard SKYBOX 5

Details

The SkyBox 5 features 5/6/7 and 10-channel control modes which works great with any type of controller, especially Blizzard's very own built-in Skywire wireless DMX receiver with built-in wireless transmitter. Plus, the built-in 4 character/4 button LCD control panel allows total control over the fixture, including master/slave, auto mode, fade, strobe settings, manual color adjustment, sound active mode, wireless ID settings, IR remote control mode, and power output mode settings.

The SkyBox 5's Lithium-Ion internal battery system which allows the user to select one of 3 power output mode settings.

Features:

  • Color mixing via 7x 15W Red/Green/Blue/Amber/White 5-in-1 LEDs
  • 2.4Ghz built-in wireless DMX receiver
  • Intelion lithium-ion battery system
  • 3 battery power modes
  • IR remote control (sold separately)
  • 5 user-selectable 32-bit dimming curves
  • Variable electronic dimming and strobe
  • Built-in color and chase macros via DMX
  • Built-in automated programs via master/slave
  • Built-in sound active programs
  • RGBAW color mixing ability in standalone mode
  • Rugged and well-built
  • Super-quiet variable-speed internal fan cooling
  • Dual mounting brackets for positioning flexibility
  • Flicker-free constant-current 400hz LED driver
  • 3-pin male input and 3-pin female output
  • PowerCon compatible AC power In/Out connectors

Specifications:

  • Operating Voltage: 90-230VAC, 50-60 Hertz
  • Power Consumption: 84W, 13A
  • LED: 7x 15-watt, 5-in-1 RGBAW LED's
  • Beam Angle: 25 degrees , 29 degrees field
  • Max. Operating Temp.: 104 degrees F (40 degrees C) ambient
  • Protocol: USITT DMX-512
  • DMX Channels: 5/6/7/10 (User Selectable)
  • Input: 3-pin XLR Male
  • Output: 3-pin XLR Female
  • Operating Modes: Standalone, Master/Slave, Sound Active, Color Preset
  • Length: 9.02" (229 mm)
  • Width: 6.5" (165 mm)
  • Height: 9" (228 cm)
  • Weight: 9.9 lbs (4.5 kg)

Wireless Receiver:

  • Transmission band: 2.4Ghz ISM (2.4-2.525Ghz)
  • Channels: 512
  • Frequency Groups: 7
  • Receiver sensitivity: -94dBm

Warranty:

  • 2-year limited warranty, does not cover malfunction caused by damage to LED's

Data_Sheet_89609_File_1.pdf
User_Manual_89609_File_2.pdf
