ETC Recessed Mount Pigtail Box - 8 Stage Pin Connectors (9408B) - 24" Pigtail
Details
We are not an authorized ETC dealer. Please contact manufacturer for warranty information.
Pigtail boxes are designed for surface or recess mounting in theaters, television studios and other spaces for distribution of lighting circuits.
Features:
- Surface and recess mounting available
- 1, 2, 3, 4, 5, 6, and 8 connectors
- 18”, 24”, 36” and 48" pigtails standard
- Connector Options:
- Edison (20A)
- Stage Pin (20, 60 and 100 amp)
- Grounded Twist-Lock (20A)
- Over and Under-hung U-bolt and C-clamp pipe mount options available
- Listed by a nationally recognized test lab (NRTL)
Physical:
- Fabricated from 18-gauge steel with 16-gauge covers and 14-gauge end caps
- Finished with black fine-textured, scratch-resistant powder coat
- 1.25” or .75” labels with white numbers on black background (sized to match product)
- • Pigtails spaced on 3” centers
