Rosco CubeConnect Dongle Receiver
Details
CubeConnect™: Wireless Control of Rosco Lighting Fixtures
Enhance the versatility of your Rosco Miro and Braq Cubes with CubeConnect™ Wireless control.
The CubeConnect™ Dongle is a 2.4GHz radio receiver which plugs right into the back of Rosco Miro Cube or Braq Cube LED fixtures and accepts wireless lighting control data from a CubeConnect™ Transceiver.
Features:
- Utilizes available power from Rosco Miro Cube and Braq Cube - no additional power needed
- Quick and easy pairing of one or more Dongles to Transceivers
- Compact and low profile form factor allows it to be used virtually anywhere
Specifications:
Power:
- Input Voltage: 5VDC
- (Input Power Adapter 100-240VAC In/5VDC Out)
Data:
- Input: DMX-512, Bluetooth Limited Energy (BLE), or Serial ASCII
- Output: DMX-512 or Mini-SSC (serial); up to 254 channels of control per Transceiver
Operating Range:
- Up to 2000' (600m) line-of-sight
- *Actual performance will vary by location and is affected by walls, partitions, and other rigid objects. See Application Notes for additional information.
Environment:
- Operating Temperature: -13° to 113° F (-20° to 45° C)
- Humidity: 0 - 95% non-condensing
Physical:
- Housing: Injection molded polycarbonate
- Dimensions: 3" x 0.88" diameter (76mm x 22mm diameter)
- Weight: 0.1 lb (0.05kg)
Approvals:
- FCC I.D. TE7WN722N & UY124
- CE
