Blizzard Komply WW5050 Waterproof Warm White LED Ribbon 5-Meter Roll with 30 LEDs per Meter
Details
At A Glance:
- 150x WW SMD LEDs per 5m reel
- IP65, outdoor rated
- Input voltage: 12VDC
Flexible, 12V WW Ribbon:
Komply™ WW5050 is an IP65 rated 12V flexible LED ribbon that has 30* warm white LEDs per meter on a 5-meter reel, and is a wonderful architectural LED lighting solution for numerous indoor or outdoor applications. There are cut points every 10cm (between every 3 LEDs), so no matter what length the situation calls for, you're sure to get a great fit!Power & Accessories:
For simple projects, you can power up to 2 rolls connected (directly) to a Komply™ LED driver and a decoder. Longer runs or wiring distances may require the use of additional accessories or setup methods. If you have any questions regarding the specific needs of an installation, please consult with a professional installer, or you can contact us directly.Overview:
- Storage temperature: -40° to 176°F (-40 to 80°C)
- Operating temperature: -13° to 140°F (-25 to 60°C)
- IP65 rated
- PCB thickness: 2mm, PCB width: 10mm
- Silicone mounting clips included
Optical:
- 30 LEDs per meter, 150 per reel
- View angle: 120°
- CCT: 2700K
- LED Brand: Epistar
- Luminous flux: 600Lm/M
Power:
- Input: 12VDC
- Max power: 7.2W/M
- 36W per full reel
- Current: 0.6 A/M
Warranty:
- 2-year limited warranty
Dimensions & Weight:
- 196.9" L x 0.4" W x 0.1" H
- 1.9 lbs
