Ayrton Mistral-S/TC 300W LED Spot 7-53° Automated Fixture - TC Monochromatic Spot Fixture

(0)No Reviews yet
SKU: Ayrton AY011250


Ayrton has once again pushed the limits with Mistral! A versatile, new fully equipped 300 W spot luminaire in the same ultra-compact format as MERAK. MISTRAL comes in two versions, each to meet the specific requirements of lighting professionals.

MISTRAL-S is designed for scenic applications. It is equipped with a new LED module, delivering powerful metallic white light with record-breaking output of 18,000 lumens and a colour temperature of 6500 K.

Devised specifically for applications that require perfect colour reproduction, MISTRAL-TC is equipped with an entirely new LED module using a monochromatic light source with a native colour rendering index greater than 90, extremely high TM30 readings and a colour temperature of 5700 K.


  • Optics:
    • 13 elements 8:1 zoom high-resolution optic system
    • Beam aperture: 6.7° to 53°
    • Fast motorised linear zoom
    • 119 mm front lens for ultimate performance
  • Light source:
    • Rated life (L70): up to 40,000 hours
    • Flicker-free source management
  • Movement:
    • Moving-head operated via either 8- or 16-bit resolution
    • High-resolution stepper motors operated via microprocessors
    • Pan and tilt with automatic repositioning
    • Moving head range: 540° (pan), 270° (tilt)
  • Colours:
    • Sophisticated colour mix system providing CMY colour mixing
    • Variable CTO colour temperature correction
    • Fixed colour wheel with seven saturated colour filters
  • Gobos:
    • Indexable rotating gobo wheel with 7 high precision glass gobos plus open position
    • Adjustable speed rotating gobo in both directions
    • Fixed gobo wheel with 9 high precision glass gobos plus open position
    • Gobo diameter: 25.0 mm
    • Image diameter: 20.0 mm
    • Gobo thickness: 1.1 mm
  • Iris diaphragm:
    • Iris range: 15 to 100% open
  • Frost:
    • Light frost filter (Heavy frost filter in option)
  • Effects:
    • Focusable graphic animation effect-wheel with continuous rotation in both directions
    • 5-facet circular indexable rotating prism
    • Sparkle effect: dynamic animation effect with speed and fade adjustment
  • Dimmer / Strobe:
    • Electronic dimmer, allowing perfect light adjustment from 0 to 100%
    • Strobe effect, with speed adjustment from 1 to 25 flashes per second
  • Hardware Features:
    • Graphic LCD display for addressing and special functions settings, with flip function
    • Clicking jog wheel to set functions
    • Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™
    • XLR 5 pin male and female connectors for DMX connection
    • powerCON TRUE1 male and female connectors for power connection
  • Control:
    • DMX 512 protocol, through DMX cable or a wireless system
    • DMX-RDM compatible
    • Stand-alone mode and Master/Slave modes
    • Local control panel, with LCD display
    • Choice of 3 DMX modes (from 26 to 39 DMX channels)
  • Power Supply:
    • Electronic supply with active PFC
    • 100 to 240 Volts – 50/60 Hz
    • Power: 450 W maximum
  • Housing:
    • Moving-head skeleton made of aluminium and steel metal plates
    • Base in die-cast aluminium
    • Heatsinks in aluminium and copper
    • Moulded covers in self-extinguishing fire retardant ABS PC (V0 class)
    • Two-side handles for transportation
    • Four heavy-duty feet for better stability
    • IP20 protection rating
    • Exterior finish: black (Carbon)
