Blizzard 12 Channel DMX Controller with Built In 2.4 Ghz Wireless DMX Transmitter

At A Glance:

• DMX512/1990 standard
• 2.4Ghz built-in wireless DMX transmitter
• Controls 16 fixtures of up to 12 channels, 192 channels total

Compact DMX Controller:

Kontrol™ 6 Skywire is the perfect compliment for lighting fixtures with 6-in-1 LEDs. Its 6 conveniently labeled red, green, blue, white, amber, and UV sliders make for ultra easy color-mixing control. It allows control of up to 16 fixtures composed of 12 channels each and up to 18 programmable scenes. Its 18 chase banks can contain up to 200 steps composed of saved scenes or manual inputs in any order.

Skywire Wireless Transmission:

It offers 6 universal channel sliders, quick access fixture and scene buttons, and an LED display for easy navigation. Then for the ultimate ease of setup, its built-in Skywire™ wireless transmitter provides reliable wireless communication for over 1000 feet, line-of-sight with 512 auto-assigning frequencies in 7 groups that can allow up to 7 systems to run simultaneously in the same space.

Overview:

• USB specification: 1.0
• Disk format: FAT16 / FAT32 ONLY
• Maximum disk size: 4GB

Warranty:

• 2-year limited warranty

Wireless Receiver:

• Operating band: 2.4Ghz ISM
• Max operating range: 1000+ feet (Line of Sight)
• Frequency groups: 7
• Max transmission power: 20dBm

Dimensions & Weight:

• 10.2" L x 5.6" W x 2.75" H
• 3.25 lbs

Power:

• Operating Voltage: 9-12 VDC, .3A (From included power supply)
