Blizzard IRiS InSignia 2.9

This item is built to order.

At A Glance:

• 2.9 mm Pixel Pitch
• 800 Nit Brightness
• IP40 (front) / IP21 (rear)

Meticulous Design

Advanced technology via NovaStar™ A8s receiving cards offer HDR10 / HLG support from the inside, while precision mechanics on the outside allow for 90° splicing, giving InSignia panels a real edge.

Versatile Digital Signage

The InSignia series meets the needs of any commercial display with easy-to-install, custom-sized LED panels ready for indoor or IP65-rated outdoor use.

High-Res, Super Bright

Choose from a high resolution, 1.9mm fine pixel display to a 10.0mm pixel pitch panel with 7,000 nit brightness for an outstanding LED display.

Specifications:

• Brightness: 800 Nit
• Certifications: FCC, ETL, CE, RoHS
• Color Depth: 14 Bit
• Curvature: 0 - 90°
• Grayscale: 14 Bit
• HDR: HDR10-Optima / HLG
• IP Rating: IP40 (front) / IP21 (rear)
• Input Power: 680 W/m2
• LED Configuration: SMD 1415 LEDs
• Lifespan: 100,000 Hours
• MAX Power usage: 150W
• Module Quantity: 2 x 2
• Panel Dimensions: 500 x 500 x 62 mm
• Panel Weight: 12.8 lbs.
• Panel Resolution: 168 x 168
• Pixel Density: 112,896 Dots/m2
• Pixel Pitch: 2.9 mm
• Receiving Card: NovaStar™ A8s-N (Customizable with Brompton processing)
• Refresh Rate: ≥3840
• Scan Mode: 1/21
• Primary Usage: Signage
• Serviceability: Front
• Special Features: Wide curvature capabilities
• Warranty: 7 Year
• Working Humidity: 10% - 90% RH
• Working TEMP: -10°C ~+40°C
