Blizzard LB Hex Alloy

At A Glance:

• 18x 18 W RGBAW+UV 6-in-1 LEDs
• 59 static colors including 32 Rosco® matched presets
• CCT control from 2,000 K to 5,700 K via DMX

HEXtrordinary Color:

LB Hex™ Alloy delivers all six colors at full strength. From rich saturates to tuned white blends, you get a wash fixture that responds exactly the way your cues demand.

Built-In Rosco Presets:

With 59 static colors including Rosco® matched options, LB Hex™ Alloy gives designers fast access to repeatable looks. No guesswork required.

Built To Handle Your Workflow:

Three DMX modes, a rugged bracket, and powerCON© TRUE1 connectivity make LB Hex™ Alloy easy to integrate into touring rigs, install systems, or quick stage builds.

Tech Specs:
The Rundown:

• 18x 18 W RGBAW+UV 6-in-1 LEDs
• 59 static colors including 32 Rosco® matched presets
• CCT control from 2,000 K to 5,700 K via DMX
• 25 degree beam angle
• Flicker free constant-current LED driver
• Auto and sound active modes plus 12 built-in shows
• 5-pin XLR in and out
• PowerCON© TRUE1 compatible power in and out
• 6, 8, or 11 channel DMX modes
• Rugged metal housing and adjustable bracket
• 2-year limited warranty

Summary:

LB Hex™ Alloy is a compact, powerful 6-in-1 LED wash fixture built for accurate color mixing and flexible control. Its 18 high-output RGBAW+UV LEDs produce deep saturates, controlled whites, and bold accent colors. With quick access to 59 static colors including 32 Rosco® matched presets, LB Hex™ Alloy integrates easily into workflows that require predictable color behavior. Designers can choose from 6, 8, or 11 channel DMX modes depending on the level of control needed, and the rugged metal housing includes a mounting bracket for fast setup in almost any orientation.

Warranty:

• 2 Year - Extendable

Optical:

• LEDs: 18x 18W RGBAW+UV LEDs
• Beam Angle: 25 degrees
• Luminous Intensity: 4,389 Lux @ 2.5M, 991 Lux @ 5M

Control:

• Protocol: USITT DMX-512, RDM
• DMX Channels: 6 / 8 / 11
• Interface: 4-button LED menu
• Modes: DMX, Master / Slave, Standalone, Auto, Sound Active

Power & Current:

• Operating Voltage: AC 110 to 240 V, 50 to 60 Hz
• Power Consumption: 144 W (1.85 A, PF 0.67)
• Max Operating Temp: 104 °F (40 °C) ambient

Dimensions:

• 10.2" x 10.9" x 4.1"
• 6.1lbs

Connectors:

• DMX In / Out: 5-pin XLR male / female
• Power: PowerCON© TRUE1 In / Out
• Mounting: Adjustable bracket with safety loop

LB Hex Alloy Cutsheet.pdf
LB Hex Alloy User Manual.pdf
LB Hex Alloy Dimensional Drawing.pdf
LB Hex Alloy Photometrics Report.pdf
