Blizzard Typhon IP Profile 1000

At A Glance:

• Airtight design to perform in any climate
• Superior shaping & visuals + Near-perfect CRI: 95
• Light on the Rig & Road (86 lbs)

Tech Specs

Performance & Versatility:

Typhon IP Profile 1000 is an IP65-rated, 1000W LED moving head fixture, engineered for outdoor use. With 540°/270° pan and tilt capabilities, electronic focus, and a motorized zoom range of 5°-50°, it offers unparalleled control, making it a versatile and essential tool for professional lighting designers.

Shaping & Visuals:

It features a 4-blade framing shutter system that’s rotatable up to 110°, along with 6 replaceable rotating gobos (+open) and 7 static gobos (+open). Additionally, it offers a bi-directional 4-facet rotating prism, frost filter, and an effect wheel, opening up endless possibilities for stunning visual effects.

Color & Creativity:

With its CMY color mixing system + CTO filter, Typhon IP Profile offers a wide range of diverse hues that are easily accessible. Its 6-color (+open) color wheel allows for color indexing and variable speed rotation via DMX, enabling users to create spectacular colored rainbow lighting effects.

Optical:

• 1,000W LED light source
• CTC: 6000K-2300K
• CRI: ≥95

Luminous intensity:

• Narrow (5°): 20,601 Lux; @ 10m. 5,150 Lux @ 20m
• Wide (50°): 610Lux @ 10m, 153 Lux @ 20m

Control:

• DMX-512, RDM
• 5-pin DMX In/Out
• 34/32/54-channel DMX
• 5-button control panel with LCD display
• DMX512, m/s, auto

Power & Current:

• 100-240VAC, 50-60 Hz
• Max power consumption: 1200W, 12.11A, PF: .99
• Fuse: 250V/15A
• PowerCON™ TRUE1-compatible AC power Input

Dimensions:

• 30.4" x 12.1" x 18.3"
• 86lbs

Warranty:

• 2 Year - Extendable

Certifications:

• IP66-rated

Blizzard Typhon IP Profile 1000 User Manual.pdf
Blizzard Typhon IP Profile 1000 Cutsheet.pdf
Blizzard Typhon IP Profile 1000 Dimensions.pdf
