ChamSys GeNetix GN2 2 Port Node

(0)No Reviews yet



  • GeNetix GN2 2 Port Node


GeNetix Node 2 is a two-port Ethernet-DMX node that is compatible with any console supporting Art-Net and sACN. GeNetix Node 2 can also be used as a USB interface for MagicQ PC systems, unlocking MagicQ into reduced mode when connected via its USB-C or Network port.

Configuration is simple, whether done locally via its in-built display, remotely with its onboard web server or from the console. Powered by either PoE or its USB-C port, this versatile device is at home in many different environments as a standalone interface, truss-mounted in the rig via its M12 receiver or installed via its DIN rail mount.

GeNetix Node 2 supports Art-Net, sACN, RDM and supports both DMX input or output from its two DMX ports.


  • 2 RDM DMX Ports supporting Input and Output
  • Supports Art-Net & sACN
  • Webserver for remote configuration
  • In-built display and encoder for local configuration
  • Can be USB or PoE powered
  • Unlocks MagicQ PC Systems into Reduced Mode via either USB or Network


Hardware Specifications:

  • RDM Direct DMX Ports: 2
  • Network Ports: 1
  • PoE Input: Yes (Port 1)
  • USB Ports: 1 USB-C
  • Kensington Security Lock Fixing: Yes
  • Power Input, Neutrik powerCON TRUE1 110 to 240 VAC

Software Specifications:

  • Art-Net/sACN: Yes
  • ChamNet Support: Yes
  • Configurable DMX Timings: Yes
  • Web Server: Yes
  • DMX Redundancy Support: Yes
  • User Scene Store: Yes

Included Accessories:

  • Neutrik powerCON TRUE1 Power Cable: 1
  • DIN Rail Mount Clip: 1
  • USB A-C Cable: 1

Node Weights and Dimensions:

  • Width: 125mm (4.92 inches)
  • Depth: 133mm (5.23 inches)
  • Height: 44mm (1.73 inches)
  • Weight: 0.85 KG (1.87 lb)
