Chauvet DJ Scorpion Dual RGB ILS

(0)No Reviews yet
$279.99
SKU: Chauvet DJ SCORPIONDUALRGBILS

Details

Let your lighting creativity run wild with Scorpion Dual RGB ILS, a Dual RGB FAT BEAM™ aerial effect laser that generates customized and ever-changing laser shows using programmable pan, tilt, and zoom effects with separate X, Y, and Z rolling effects and scan speed adjustment. This laser features 32 built-in patterns, including the popular “Laser Sky” effect offers perfect color combinations by mixing red, green, and blue laser diodes. Its unique dual mirror output makes a great centerpiece or side accent in pairs. Scorpion Dual RGB ILS has ILS compatibility with the cutting-edge Integrated Lighting System (ILS) that makes creating coordinated light shows across different fixture types easy. D-Fi™ USB compatibility is also on board for wireless Master/Slave or DMX control. Scorpion Dual RGB ILS is fully FDA compliant, variance-free, and ready to use right out of the box. Easily operate Scorpion Dual RGB ILS in automatic, Master/Slave, manual or sound-activated mode. Wireless control is also possible using the optional IRC-6 remote.

Features:

  • Dual RGB FAT BEAM™ aerial effect laser, perfect for events with fog or haze
  • D-Fi™ USB compatibility for wireless Master/Slave or DMX control
  • Create perfect color combinations by mixing red, green, and blue laser diodes
  • Unique dual mirror output that makes a great centerpiece or side accent in pairs
  • 32 built-in patterns, including the popular “Laser Sky” effect
  • Wireless control using the optional IRC-6 remote
  • Generate customized and ever-changing laser shows using programmable pan, tilt, and zoom effects with separate X, Y, and Z rolling effects and scan speed adjustment
  • Fully FDA compliant, variance-free and ready to use right out of the box
  • Easily operate in automatic, Master/Slave, manual or sound-activated mode
  • Fits best in the CHS-40 VIP Gear Bag

Specifications:

  • DMX Channels: 10
  • DMX Connectors: 3-pin XLR
  • Pan and Tilt: 30°/30°
  • Light Source: 638 nm/30mW (red) laser diode, 520 nm/20 mW (green) laser diode, 450 nm/ 50 mW (blue) laser diode
  • Strobe Rate: 0 to 27 Hz
  • Zoom Angle: 1° to 29°
  • Coverage Angle:36°
  • Power Linking: 27 units @ 120 V; 48 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 20 W, 0.3 A @ 120 V, 60 Hz ; 19 W, 0.2 A @ 230 V, 50 Hz
  • Weight: 3.8 lb (1.7 kg)
  • Size: 8.5 x 7 x 6.3 in (216 x 179.5 x 161 mm)
  • Approvals: CE, FDA
  • Bracket Mounting Hole: M12
  • Ambient Operating Temperature: 59 °F to 95 °F (15 °C to 35 °C)
  • Classified per 21 CFR 1040.10 & .11
  • Complies with US FDA CDRH laser safety standards 21 CFR 1040.10 & 1040.11
  • Optional Controllers: IRC-6

What's Included:

  • Scorpion Dual RGB ILS
  • Power cord
  • Quick Reference Guide

Scorpion Dual RGB ILS - User Manual.pdf
