Chauvet Professional COLORado Solo Edge 3

Chauvet Professional's COLORado Solo Edge 3 is a low-profile, one-meter IP65-rated footlight features an RGBwWL source and a single lens for smooth, high-quality color and white light output.

Integrated RGB marker lights provide talent cues while its end-to-end design creates seamless, gap-free arrays for stage and broadcast applications.

Low-profile, 1m, IP65 rated footlight with full-color and high-quality white light

Single-source lens for smooth, even output with no distracting points of light and an additional “stealth” filter to help the fixture disappear when off

Additional, fully controllable RGB marker lights can be used to cue talent or mark the edge of a stage

Designed for end-to-end use with no gaps or distracting cable mess, and a covered display to keep everything elegant unseen.

This low-profile, 1-meter, IP65-rated RGBwWL LED footlight projects high-quality white light and a full range of color through a single-source lens designed to produce smooth, even output. Featuring fully-controllable RGB marker lights that can be used to cue talent or mark the edge of a stage, seamless end-to-end alignment, and a covered display, this elegant fixture also comes with a stealth filter that enables it to disappear when off.

Features:
High-Quality Theatrical Light:

An advanced RGBwWL LED system delivers a full color spectrum and high-CRI white light, all housed in a rugged IP65-rated frame.

Smooth, Unseen Output:

A single-source lens produces smooth, even washes, while the included stealth filter helps the fixture visually disappear when not in use.

Integrated Stage Markers:

Fully controllable RGB marker lights are built directly into the fixture to provide clear visual cues for talent or define stage boundaries.

Seamless End-To-End Design:

Create perfectly aligned, gapless arrays with end-to-end connections and a covered display that keeps the focus on the light, not the hardware.

Optical:
Light Source:

• Primary: 112 LEDs (Quintuple-color RGBwWL)
• RGB Markers: 12 LEDs (Tri-color RGB)
• Color Temperature (range): 2800 to 8000 K
• Color Temperature (at full): 6329 K
• CRI @ 3200K: 92.5

Beam Angle:

• Horizontal: 116.4°
• Vertical: 121.5°
• Horizontal (Stealth Filter): 89.5°
• Vertical (Stealth Filter): 91.6°

Field Angle:

• Horizontal: 148.4°
• Vertical: 158°
• Horizontal (Stealth Filter): 131.4°
• Vertical (Stealth Filter): 137.4°

Lumens:

• Without Stealth Filter: 17,416
• With Stealth Filter: 4,144

Illuminance:

• Without Stealth Filter: 235 lux @ 5 m
• With Stealth Filter: 82 lux @ 5 m

Dynamic Effects:

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 30Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Dim Curves: 4
• Built-in Automated Programs: Yes
• Customizable Programs: Yes

Construction / Physical:

• Dimensions: 39.37 x 8.85 x 2.51 in (1000x 225 x 64mm)
• Weight: 22 lb (10 kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy and Aluminum die-cast
• IP Rating: IP66

Connections:

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 5-pin IP65 XLR, Seetronic etherCON
• Cable Length (power): 5 ft (1.5 m)
• Software Connection: USB, Ethernet (RJ45)

Control:

• Control Protocol: Art-Net, sACN, DMX, RDM

DMX Channels:

• 1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
• 2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
• 4 Cell: 14, 15, 15, 18, 22, 33, 37, 41,42 or 69

Art-Net Channels:

• 1 Cell: 5, 6, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
• 2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
• 4 Cell: 14, 15, 15, 18, 22, 33, 37, 41,42 or 69
• Modes/Personalities: personalities (32)

Electrical:

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 5 units @ 120 V; 10 units @ 208 V; 11 units @ 230 V;
• Power and Current: 242 W, 2.03 A @ 120 V, 60 Hz
• Power and Current: 237 W, 1.18 A @ 208 V, 60 Hz
• Power and Current: 236 W, 1.06 A @ 230 V, 50 Hz

Battery:

• Battery type: Lithium Ion
• Rechargeable: Yes

Battery Power:

• Li-ion Battery: 3.7Vdc, 200mAh
• Li-Button: 3Vdc, 1000mAh

Certifications / Qualifications:

• Compliance: CE, MET, FCC
• MET Listing Number: [E113093-1110, E113093-1125]
• US Safety: [UL 60950-1]

Thermal Dissipation:

• @ 120V: 819 BTU per hour
• @ 208V: 819 BTU per hour
• @ 230V: 819 BTU per hour
• Temperature (Ambient): -4 °F to 122 °F (-20 °C to 50° C)

Optional Accessories:

• Professional Clamps : CTC-50HC, CTC-50HCN
• Riglink TR1 Cables
• Riglink IP DMX cables
• Riglink IP Network cables

What's Included:

• COLORado Solo Edge 3
• Seetronic Powerkon IP65 power cord
• Power and Data linking cables
• Stealth Filter
• 2 Omega bracket with mounting hardware
