Chauvet Professional Maverick Storm 2 Profile
Details
Key Features:
- Single 580W LED Profile Light
- CMY + CTO Color Mixing System
- 10:1 Zoom
- 28,000 Lumens Output
- 1 x Rotating Gobo Wheel
- 1 x Static Gobo Wheel
- CRI & CTB Filters
The Maverick Storm 2 Profile from CHAUVET Professional packs an impressive array of features into one of the lightest mid-sized IP65-rated moving profile fixtures within its category. Engineered to meet the demands of designers seeking a versatile compact powerhouse, the Maverick Storm 2 Profile seamlessly blends the latest technical advancements from the Maverick series with exceptional durability and adaptability for both indoor and outdoor use.
Harness the impressive 28,000 lumens output with precision using its finely tuned framing shutter system. You can narrow down the beam to a razor-sharp 5.5° angle and unleash your creativity with its versatile wheelhouse, offering variable CMY + CTO color mixing, a color wheel with CRI and CTB filters, static and rotating gobo options, a five-facet prism, iris control, and frost effects.
Designed to withstand various weather conditions, this Maverick model features SunShield technology, ensuring complete protection of all internal optical components whenever the fixture is powered down, thus ready to face any challenge from stormy nights to sunny days.
Features at a Glance:
- Fully featured, compact and lightweight IP65 580W LED yoke profile fixture
- 16-bit dimming of master dimmer for smooth control of fades
- Variable CMY + CTO color mixing system to create a wide palette of colors
- CRI and CTB filters on color wheel for added flexibility
- One rotating, indexing, and interchangeable slot and lock gobo wheel
- One rotating static gobo wheel
- DMX, WDMX, sACN, and Art-Net for full flexibility of control options
- RDM control over DMX for fixture reporting
- 6.3 to 58.6° zoom range for variable beam sizes
- Iris, 5-facet prism, and frost for beam control
- Integrated sun shield for protecting the optical path from sunlight when the fixture is off
- Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup
- USB slot for software uploads
- Battery backup display with auto-rotate depending on fixture orientation
Key Specs:
- Fixture Type: Gobo Projector / Moving Head
- Light Source: 1x White LED - 580 W / 4.2
- Colors: Unspecified Colors (Included Gels/Filters)
- Beam Angle: 6.3 to 42.6°
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- AC Input Power: 100 to 240 VAC, 50/60 Hz
- Mounting: Omega Bracket
Power / Current Consumption:
- 100 VAC, 60 Hz: 800 W / 8.2 A
- 120 VAC, 60 Hz: 800 W / 6.82 A
- 208 VAC, 60 Hz: 779 W / 3.77 A
- 230 VAC, 50 Hz: 763 W / 3.41 A
- 240 VAC, 50 Hz: 767 W / 3.34 A
Light:
- Fixture Type: Gobo Projector / Moving Head
- Light Source: 1x White LED - 580 W / 4.2
- Expected Lamp Life: 50,000 Hours
- Colors: Unspecified Colors (Included Gels/Filters)
- Photometrics: 6682 fc / 71,933 Lux at 16.4' / 5 m, 239 fc / 2580 Lux at 16.4' / 5 m
- Color Temperature: 6963K
- Lumen Output: 28,534 Lumens (Output)
- Beam Angle: 6.3 to 42.6°
- Field Angle: 7.9 to 54.7°
- Shutter / Strobe: Electronic
- Focus: Motorized
- Zoom Adjustment: Motorized, 5.5 to 58.6°
- Dimming: 16-Bit Electronic with 4 Dimmer Modes
- Prism: 5-Facet (Rotating)
Performance:
- Operating Modes: Automatic, Color Change, Color Dimmer, DMX, Move-in-Black
- Macros / Programs: Color Wash, Auto-Program, Color Temperature, Color Fade, Framing Macro, Prism Macro, Frost Macro
- Effects: Gobo Scroll, Move-in-Black
- Strobe Rate: 0 to 20 Hz
- Gobos: 7x Removable Glass Spot/Open, 9x Removable Glass Spot/Open
- Color Accuracy Index: CRI: 71.3 to 89.1
Movement:
- Tilt Ranges: 270° / 180° / 90°
- Pan Ranges: 540° / 360° / 180°
Control:
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- DMX Channel Modes: (2 Modes)32 / 48-Channel
- Remote Control: Yes
- Mobile App Compatible: No
Connectivity:
- Inputs/Outputs: 1 x RJ45 Data/Network Input/Output, 1 x XLR 5-Pin DMX/Data Input/Output
- Wireless: No
Power:
- AC Input Power: 100 to 240 VAC, 50/60 Hz
- AC Power Connector: Input: 1x Seetronic IP-Rated, Output: 1x Seetronic IP-Rated, Cord Length: 5' / 1.5 m
- Fuse: F 15 A 250 V
Power / Current Consumption:
- 100 VAC, 60 Hz: 800 W / 8.2 A
- 120 VAC, 60 Hz: 800 W / 6.82 A
- 208 VAC, 60 Hz: 779 W / 3.77 A
- 230 VAC, 50 Hz: 763 W / 3.41 A
- 240 VAC, 50 Hz: 767 W / 3.34 A
Environmental:
- Environmental Protection: Weather-Resistant (IP65)
- Operating Temperature: 4 to 113°F / -15 to 45°C
Physical:
- Mounting: Omega Bracket
- Included Accessories: 1x Power Cable
- Exterior Color: Black
- Max Housing Temperature: 113°F / 45°C
- Cooling: Convection, Fan
- Certifications: CE, MET, FCC
- Dimensions: 27.5 x 15.3 x 9.9" / 699 x 388 x 252 mm
- Weight: 67 lb / 30.4 kg
In the Box:
- CHAUVET PROFESSIONAL Maverick Storm 2 Profile
- Seetronic Powercon IP65 Power Cord
- Omega Bracket with Mounting Hardware
- Limited 2-Year Manufacturer Warranty
