Chauvet Professional Ovation F-915FC

A high-power, full-color Fresnel fixture utilizing an RGBAL LED system to project a bright, soft field of light with a versatile motorized zoom.

Suited for theatrical stages, broadcast studios, and event spaces that demand a high-quality, soft-edged wash with full-color mixing and precise zoom control.

Ovation F-915FC is a high-power, full color mixing Fresnel style fixture that utilizes our RGBAL LED system. This fixture projects a bright beautifully soft, field of light from subtle pastels to punchy saturates and nearly any temperature of white. A motorized zoom with a 17° – 85° field range allows you to add light where it is needed. Control of the virtual color wheel, zoom and output can be via DMX or on-board dials.

At A Glance:

• Features an advanced RGBAL LED system for a full spectrum of vibrant colors and whites.
• Delivers a versatile motorized zoom range, adjustable from a tight 17° to a wide 85° wash.
• Includes a virtual color wheel and variable CCT presets from 2800 K to 6500 K.
• Ensures smooth fades with 16-bit dimming and flicker-free output via adjustable PWM.
• Built for sound-sensitive environments with a virtually silent convection cooling system.
• Offers flexible control via DMX and RDM, plus onboard dials for manual adjustments.

Features:

• Full Color RGBAL Fresnel: Provides a full-spectrum, five-color LED engine for rich color rendering in theatre, film, and production.
• Soft, Even Light Field: Produces a beautifully soft and consistent field of light for flawless illumination.
• Motorized Zoom: Offers a smooth, motorized zoom range from a narrow 17° spot to a wide 85° wash.
• High-Resolution 16-Bit Dimming: Achieve exceptionally smooth fades with precise 16-bit control over the master dimmer and individual colors.
• Onboard Control: Easily adjust color, zoom, and dimming directly on the fixture for quick, manual operation.
• Virtual Color Wheel: Instantly access a range of popular gel colors using the convenient virtual color wheel.
• Variable White Color Temperature: Select from a wide range of preset color temperatures from a warm 2800 K to a cool 6500 K.
• Remote Device Management (RDM): Remotely configure and monitor the fixture using RDM for enhanced operational flexibility.
• Adjustable PWM: Eliminate on-camera flicker by adjusting the Pulse Width Modulation to match your camera’s frame rate.
• Silent Operation: Operates with virtually no noise, making it perfect for sound-sensitive studio and theatre environments.

Specifications:
Optical:

• Light Source: 89 LEDs (18 red, 18 green, 16 blue, 16 amber, 21 lime) 3 W, (1.13 A), 3698 K, 50,000 hours life expectancy
• Color Temperature (range): 2800 to 6500 K
• CRI (3200 K): 90
• Beam Angle: 17° to 54°
• Field Angle: 30° to 85°
• Zoom Range: 17° to 85°
• Lumens (30°): 4,294
• Lumens (73°): 6,661
• Illuminance (30°): 1,980 lux @ 5 m
• Illuminance (85°): 433 lux @ 5 m
• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dynamic Effects:

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 27 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes

Construction/Physical:

• Dimensions: 17.80 x 12.59 x 10.82 in (452 x 320 x 275 mm)
• Weight: 19 lb (8.6kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy, Aluminum die-cast

Connections:

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)

Control:

• Control Protocol: DMX, RDM
• DMX Channels: 1, 3, 5, 7, 11, 13, 14 or 17
• Modes/Personalities: 8 personalities (1, 3, 5, 7, 11, 13, 14, 17, HSV)

Electrical:

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 4 units @ 120 V; 8 units @ 208 V; 8 units @ 230 V
• Power and Current: 304 W, 2.576 A @ 120 V, 60 Hz
• Power and Current: 293 W, 1.490 A @ 208 V, 60 Hz
• Power and Current: 293 W, 1.358 A @ 230 V, 50 Hz

Certifications/Qualifications:

• Certifications: CE, MET, FCC, UKCA
• IP Rating: IP20, dry location
• Noise Levels: Idle: 0.4 dB(A) @ 1 m
• Auto: 16.8 dB(A) @ 1 m
• On: 30.2 dB(A) @ 1 m
• Off: 11.6 dB(A) @ 1 m
• Silent: 18.8 dB(A) @ 1 m

Compatible Accessories:

• Professional Clamps: CTC-50HC, CTC-50HCN
• Neutrik® powerCON® cables
• 3-pin or 5-pin DMX Cables
• Color Blending Filters: DF60X1D, DF20D
• Ovation F 7.5” Barndoor V2
• Ovation Pole Operated Yoke 2 – 8”
• Seetronic Powerkon IP65 cables

What's Included:

• Ovation F-915FC
• Seetronic powerkon IP65 power cord
• Gel frame (7.5 in/191 mm accessories)
