Chroma-Q Magic Box PS12 Power Supply

The Magic Box PS12 power supply has a maximum capacity of 12PU and features 3 individual XLR4 outputs each with terminated return inputs. The PS12 has been designed for cable loops of up to 66m / 200ft per output. The unique Magic Box interlocking enclosure facilitates rack mounting when used in pairs and truss mounting via captive nut insert.

Features:

• Provides 3 circuits of combined 24VDC power and DMX signal
• Designed for cable loops of up to 60m / 200ft per output
• Features 3 individual XLR4 outputs each with terminated return inputs
• Provides a maximum power capacity of 12PU
• Unique Magic Box interlocking enclosure
• Designed for customized front house racks

Specifications:

• Power: 100-240V, 50/60Hz, 200W, IEC chassis male
• Control: ANSI E1.1 DMX-512, XLR5 in and through
• Dimensions: 8.6" (220mm) x 3.5" (88mm) x 11" (280mm)
• Weight: 3.2kg / 7.1lbs
