Clear-Com HME DX121 System With HS15 Headset

DX121 System with HS15 headset. The HME DX121 system is comprised of the BS121 base station, BP200 beltpack or WH200 wireless headset, and compatible headsets. The DX121 supports 1 full-duplex or 4 push-to-transmit shared beltpacks, while providing interface option to 4-wire intercom systems only. It is a highly portable and versatile system that can be plugged directly into the headset jack of any intercom station or into a four-wire connection of a device such as a digital matrix intercom. The 2.4 GHz frequency-hopping, Spectrum Friendly technology allows up to eight DX121's to be used together to support multiple channel applications. The DX121 can be used to support wireless channels for theatrical and live crew events, broadcast control room operators, technical support crews and for connecting remote staff at large venues.

System Highlights:

• Headset Connector Connectivity
• Four-Wire Connectivity
• Built-In Battery Charger
• Digital Frequency-Hopping Spread Spectrum (FHSS)
• Power Backup with Fully Charged Battery in Charger Port
• HME Spectrum Friendly Technology

System Includes:

• (1) BS121 Base Station
• (1) HS15 Single Muff Headset with Noise Canceling Mic
• (1) BP200 Beltpack
• (1) Beltpack Pouch
• (2) BAT41 Battery Li-ion Rechargeable
• (1) DX121 HS-XLR4F Interface Cable
• (1) 12VDC 60W Power Supply (100/240VAC Universal)
• (1) 115VAC Power Cord

BS121 Base Station Features:

• Headset Connector Connectivity can be connected to most hardwired intercom headset jacks for instant wireless communication.
• Four-Wire Connectivity interfaces to four-wire/matrix intercoms and radio based communication systems. Assignable relay closure for advanced functionality.
• Built-In Battery Charger One-port battery charger charges a remote Communicator® battery in under three hours.
• Spectrum Friendly™ Frequency Range can be selected for low band only (2401.92 - 2439.936 MHz) high band only (2443.392 - 2481.408 MHz) or full band (2400-2483.5 MHz).
• Digital Frequency-Hopping, Spread Spectrum (FHSS) Encryption Technology ensures confidential communication. Approved for worldwide use.
• Assignable Relay Closure provides advanced functionality when used with matrix intercoms or radio based communication systems.
• Expandable, compatible with the entire HME DX 200 and 100 series of digital wireless intercom products.
• Four-Wire I/O Connection 600 Ω balanced, level adjustable.
• Headset I/O Connection 200 Ω, level adjustable for interfacing to a Dynamic MIC headset connector.

BP200 Beltpack Features:

• Super Compact Design makes the beltpack the industry’s lightest, at only 7.4 ounces (0.21 kg).
• Rechargeable Lithium-Ion Batteries provide up to 20 hours of beltpack operation with each charge.
• Internal Antennas are housed inside the beltpack for extra protection and durability.
• Voice Prompts inform users of status changes and system diagnostics through the headset, such as "low battery."
• Completely Sealed Buttons dramatically enhance the life of the beltpack by keeping dirt and moisture out and preventing mechanical failures.
