ETC Recessed Mount Pigtail Box - 6 Stage Pin Connectors (9406B) - 48" Pigtail

Pigtail boxes are designed for surface or recess mounting in theaters, television studios and other spaces for distribution of lighting circuits.

Features:

• Surface and recess mounting available
• 1, 2, 3, 4, 5, 6, and 8 connectors
• 18”, 24”, 36” and 48" pigtails standard
• Connector Options:
  • Edison (20A)
  • Stage Pin (20, 60 and 100 amp)
  • Grounded Twist-Lock (20A)
• Over and Under-hung U-bolt and C-clamp pipe mount options available
• Listed by a nationally recognized test lab (NRTL)

Physical:

• Fabricated from 18-gauge steel with 16-gauge covers and 14-gauge end caps
• Finished with black fine-textured, scratch-resistant powder coat
• 1.25” or .75” labels with white numbers on black background (sized to match product)
• Pigtails spaced on 3” centers
