ETC Retractable Lighting Position 3-20A Circuits - GTL & 1-Net - RJ45 (RLP-CN)

(0)No Reviews yet
SKU: ETC 7099A1302-2

Add this item to get free shipping! (Motor Freight / Oversized Excluded)


Trying to avoid permanent lighting positions and yet still need a few lights for special events? The RLP offers a flexible option -- an extra lighting position and power for a few additional lights when needed. A non-obtrusive, retractable hanging/plugging device for architectural surroundings.


  • Non-obtrusive, retractable device
  • Rated for up to 1,000 pounds
  • Two-position mechanism stored, working
  • All wiring housed inside
  • Simple ceiling plate with finger-operated latch
  • UL and cUL Listed

Receptacle configurations:

  • 4 Edison
  • 4 Stage pin
  • 4 Twist-Lock®
  • A DMX receptacle can replace any one power connector


  • Designed to hang and power standard theatrical lighting fixtures
  • UL and cUL LISTED


  • Receptacles wired through flexible conduit to a terminal box on fixed upper section of device
  • 4 panel mount outlets on sliding section, connector options include:
    • 20A Parallel Blade (Edison NEMA 5-20R)
    • 20A Stage Pin
    • 20A Twist-Lock (NEMA L5-20R)
  • Low-Voltage Connector Option – in place of one power connector:
    • 5-Pin XLR connector for DMX


  • 11-gauge steel construction
  • Fine-textured, scratch resistant white powder-coat paint
  • Standard 5 square-inch white ceiling plate with latch
  • Supports up to 1,000 pounds within 6” of center
  • Supports up to 300 pounds from any point on the included pipe
  • Installation mounting hardware for permanent support connection to structure required by others
  • Finger operated latching mechanism holds sliding device in place above ceiling
  • Spring loaded system prevents rapid descent
  • 26 inch clearance required for RLP in stored position (Ceiling to top of unit)
  • 16 inch drop from ceiling to ceiling plate in working position (Ceiling to bottom of unit)
  • 42 inch Schedule 40 1-1/2 inch black pipe included
