ETC Retractable Lighting Position 3-20A Circuits - Stage Pin & 1-DMX (RLP-BX)

Trying to avoid permanent lighting positions and yet still need a few lights for special events? The RLP offers a flexible option -- an extra lighting position and power for a few additional lights when needed. A non-obtrusive, retractable hanging/plugging device for architectural surroundings.

Features:

• Non-obtrusive, retractable device
• Rated for up to 1,000 pounds
• Two-position mechanism stored, working
• All wiring housed inside
• Simple ceiling plate with finger-operated latch
• UL and cUL Listed

Receptacle configurations:

• 4 Edison
• 4 Stage pin
• 4 Twist-Lock®
• A DMX receptacle can replace any one power connector

Specifications:
General:

• Designed to hang and power standard theatrical lighting fixtures
• UL and cUL LISTED

Electrical:

• Receptacles wired through flexible conduit to a terminal box on fixed upper section of device
• 4 panel mount outlets on sliding section, connector options include:
  • 20A Parallel Blade (Edison NEMA 5-20R)
  • 20A Stage Pin
  • 20A Twist-Lock (NEMA L5-20R)
• Low-Voltage Connector Option – in place of one power conne(more...)
