ETC Retractable Lighting Position 4-20A Circuits - GTL (RLP-C)
Details
Trying to avoid permanent lighting positions and yet still need a few lights for special events? The RLP offers a flexible option -- an extra lighting position and power for a few additional lights when needed. A non-obtrusive, retractable hanging/plugging device for architectural surroundings.
Features:
- Non-obtrusive, retractable device
- Rated for up to 1,000 pounds
- Two-position mechanism stored, working
- All wiring housed inside
- Simple ceiling plate with finger-operated latch
- UL and cUL Listed
Receptacle configurations:
- 4 Edison
- 4 Stage pin
- 4 Twist-Lock®
- A DMX receptacle can replace any one power connector
Specifications:
General:
- Designed to hang and power standard theatrical lighting fixtures
- UL and cUL LISTED
Electrical:
- Receptacles wired through flexible conduit to a terminal box on fixed upper section of device
- 4 panel mount outlets on sliding section, connector options include:
- 20A Parallel Blade (Edison NEMA 5-20R)
- 20A Stage Pin
- 20A Twist-Lock (NEMA L5-20R)
- Low-Voltage Connector Option – in place of one power connector:
- 5-Pin XLR connector for DMX
- Mechanical:
- 11-gauge steel construction
- Fine-textured, scratch resistant white powder-coat paint
- Standard 5 square-inch white ceiling plate with latch
- Supports up to 1,000 pounds within 6” of center
- Supports up to 300 pounds from any point on the included pipe
- Installation mounting hardware for permanent support connection to structure required by others
- Finger operated latching mechanism holds sliding device in place above ceiling
- Spring loaded system prevents rapid descent
- 26 inch clearance required for RLP in stored position (Ceiling to top of unit)
- 16 inch drop from ceiling to ceiling plate in working position (Ceiling to bottom of unit)
- 42 inch Schedule 40 1-1/2 inch black pipe included
