Electro-Voice Front-Loaded Two-Way 3in. Driver Loudspeaker - 90 x 90 - PI-Weatherized - 12in. - White

(0)No Reviews yet
$4,091.00
SKU: Electro-Voice EVF-1122D/99-PIW

Details

EVF-1122D/99 features a 90 degrees x 90 degrees rotatable waveguide, design for near field wide throw raw spread coverage pattern.

Features:

  • 3-inch DH7N titanium/neodymium HF compression driver
  • Rotatable Constant-directivity waveguide
  • Six available patterns with coverage from 60º to 120º
  • 97 dB sensitivity, 131 dB maximum SPL
  • Power handling: 600 W continuous, 2400 W peak
  • 4th-order passive crossover with HF protection
  • Trapezoidal 13-ply birch enclosure in three finishes: EVCoat, PI, and fiberglass (FG)

Specifications:

  • Environmental Specs: Standard versions: IEC 60529 IP44, PI and FG versions: IEC 60529 IP55
  • Input Connections: Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover
  • Frequency Response (-3 dB): 57 - 18000 Hz
  • Frequency Response (-10 dB): 49 - 21000 Hz
  • Recommended High-Pass Frequency: 65 Hz
  • Sensitivity 1 W/1 m: 97 dB
  • Max. SPL/1m (calc): 131 dB
  • Coverage (Nominal -6 dB) H: 90 degrees
  • Coverage (Nominal -6 dB) V: 90 degrees
  • System Power Handling (Continuous/Program/Peak): 600/1200/2400 Watts
  • LF Transducer: DVX312A 12-inch (305 mm) woofer
  • LF Nominal Impedance: 8 Ω
  • HF Transducer: DH7N 3-inch (76mm) diaphragm compression driver
  • Crossover Frequency: 1300 Hz
  • Nominal Impedance (Passive): 8 Ω
  • Minimum Impedance: 6 Ω
  • Enclosure Material: 13-ply weather-resistant birch with EVCoat
  • Grill: 16 GA powder-coated galvanneal with screen behind
  • Suspension: (22) M10 threaded suspension points
  • Height: 768.6 mm (30.26")
  • Width: 406.3 mm (16")
  • Depth: 413.3 mm (16.27")
  • Weight Net: 29.7 kg (65.48 lbs)
  • Shipping Weight: 34.4 kg (75.84 lbs)

Data_Sheet_93579_File_1.pdf
User_Manual_91557_File_2.pdf
