Electro-Voice Front-Loaded Two-Way 3in. Driver Subwoofer - 1000W - Fiberglass - 15in. - Black

The Electro-Voice EVF-2151D is a high-power, front-loaded bass element that can be used in a variety of applications where high-quality sound reinforcement is required in a lightweight package.

The EVF-2151D utilizes two DVX3159A 15" woofers, developed using FEA optimization for motor, suspension, and electrical design to ensure very low distortion and maximum intelligibility at high SPL.

Features:

• High power for installations
• Two premium DVX3159A woofers
• 101 dB sensitivity, 137 dB max SPL
• Power: 1000 W cont., 4000 W peak
• Trapezoidal 13-ply birch enclosure
• EVCoat, PI, or fiberglass (FG) finish
• M10 suspension points (28)

Specifications:

• Coverage (Nominal -6 dB): Omnidirectional in normal operating range
• Environmental Specs: Standard versions: IEC 60529 IP44. PI and FG versions: IEC 60529 IP55
• Input Connections: Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover
• Nominal Impedance: Passive: N/A, Bi-amp: 4 Ω Biamp
• Frequency Response (-3 dB): 40 - 2600 Hz
• Frequency Response (-10 dB): 30 - 3200 Hz
• Recommended High-Pass Frequency: 35 Hz
• Sensitivity 1 W/1 m: 101 dB
• Max. SPL/1m (calc): 137 dB
• Coverage (Nominal -6 dB) H: Omnidirectional °
• Coverage (Nominal -6 dB) V: Omnidirectional °
• System Power Handling (Continuous/Program/Peak): 1000/2000/4000 Watts
• LF Transducer: Two DVX3159A 15-inch (381 mm) drivers
• Minimum Impedance: Passive: N/A, Bi-amp: 2.7 Ω Biamp
• Enclosure Material: 13-ply weather-resistant birch with EVCoat
• Grill: Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind. PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind
• Suspension: (28) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)
• Height: 768.6 mm (30.26")
• Width: 675.6 mm (26.6")
• Depth: 726.4 mm (28.6")
• Weight Net: 53.1 kg (117.07 lbs)

Data_Sheet_93998_File_1.pdf
User_Manual_91557_File_2.pdf
