Electro-Voice 2-Way Full-Range Loudspeaker - 12in - 600W - 60x60 - WHT

The Electro-Voice Zx3 is the new standard of no compromise audio performance and versatility in a simple to use, compact package.

Features:

• DVX3121 12" LF Transducer with Forced Air Cooling
• ND2 2" Voice Coil, 1" Exit Neodymium Compression Driver
• 90 degrees x 50 degrees Coverage Pattern
• 600W Continuous (2400W Peak) Power Handling
• High Sensitivity, 131 dB Maximum SPL
• Adjustable Monitor Angle (45 degrees or 55 degrees )
• 2 Anchor Plates for Single Stud Fittings and 7 Integral Suspension Points
• Available in Black or White
• Passive/Biamp Selectable
• Full Line of Accessories

Specifications:

• Freq. Response (-3 dB): 58 Hz - 15 kHz
• Freq. Range (-10 dB): 48 Hz - 20 kHz
• Rec. Hipass Frequency: 50 Hz
• Axial Sensitivity: 97 dB (1W/1m)
• Max. Calculated SPL: 131 dB
• Horizontal Coverage: 90 degrees
• Vertical Coverage: 50 degrees
• Power Handling (Passive): 600W Continuous, 2400W Peak
• LF Power Handling (Biamp): 500W Continuous, 2000W Peak
• HF Power Handling (Biamp): 40W Continuous, 160W Peak
• LF Transducer: DVX3121, 12" (305mm) Driver
• HF Transducer: ND2, 1" (25.4mm) exit Neodymium Compression Driver
• Crossover Frequency: 2 kHz
• Nominal Impedance: 8 Ohms
• Minimum Impedance: 6.2 Ohms
• Connectors: (2) Neutrik Speakon NL4's
• Enclosure Material: Polypropylene Structural Foam
• Suspension: Enclosure has locations for 4 Single-Stud Attachment Plates and 10 Forged Steel Eyebolts - 2 on Top, 2 on Bottom, 2 on Side, and 1 on Rear of Enclosure
• Grille: Polyester Powder Coated, 16GA
• Galvanized Steel, with Rotatable Logo
• Dimensions (H x W x D): 613mm x 397mm x 362mm (24.14" x 15.64" x 14.26")
• Net Weight: 19.8 kg (43.7 lbs)
• Shipping Weight: 22.1 kg (48.6 lbs)
