ElektraLite Data Air DMX Transmitter

(0)No Reviews yet
$99.00
SKU: Elektralite DATA T

Details

The elektraLite DataAir brings wireless functionality to DMX distribution with easy plug‐and‐play convenience for fast and powerful control.

Designed to be low‐profile and quick to use, the elektraLite DataAir is no larger than a ballpoint pen and is plug‐and‐play ready, requiring only the power supply to operate. A 5‐pin connector plugs right into the input or output (depending on transmitting or receiving data), and is configured with a simple onboard LED color display. The system is configurable with up to seven individual wireless networks working simultaneously without interference from each other and allows for up to seven DMX universes to be utilized for maximum control.

The elektraLite DataAir is perfect for performance spaces both indoor and out as well as temporary stages, architectural and portable lighting applications, and exterior enclosures in hard‐to‐reach places.

Features:

  • Plug‐and‐play technology is ready to use out of the box; additional features and options configurable with only a few pushes of a single hidden button
  • Up to seven distinct networks available for transmitting multiple universes of DMX wirelessly
  • 1,500 feet approx. range for complete coverage of your DMX-controlled equipment
  • Highly‐effective GFSK modulation design with 126 channels of self‐adjusting frequency for enhanced network protection providing a high level of anti‐jamming security
  • Providing a high level of anti-jamming security
  • Signal data is real time, eliminating delay when transmitting
  • Low profile form factor for use in a diverse array of applications, including portable locations and exterior enclosures where hardwire data is difficult or impossible
  • Use multiple receivers with only one transmitter for maximum coverage with minimum hardware
  • Low‐profile design allows for maximum portability, quick storage, and easy installation

Specifications:

  • Display: Tricolor LED Display (transmitter)
  • DMX Signal Port: 5-pin XLR DMX female receptacle (Tx)
  • Input Voltage: 5VDC 500mA MIN
  • Power Input: 100-240VAC, 50/60 Hz – 0.2A Max
  • Power Output: 9V = 0.5A
  • Communication Distance: 1,500 feet approx.
  • Transmission Frequency: 2.4GHz ISM Band with GFSK Modulation (126 channels automatically jumping frequency) including anti-jamming ability to ensure working reliability
  • Transmission Bandwidth: 2.400-2.525GHz
  • Operating Temperature: -20°C-45°C – 10%-90%RH
  • Receiver Sensitivity: -106dBm
  • Materials: corrosion-proof aluminum & ABS plastic
  • Ratings/Certifications: IP65 (transmitter/receiver) IP20 (power supply)
  • Physical: L 4″ W 1″ H 8.5″
  • Weight: 0.3 lbs / 0.13 Kgs


Data_Sheet_100115_File_1.pdf
