Froggy's Fog Poseidon Aqua 2 - Ultrasonic Low Fog Generator
Details
The Froggy's Fog - Poseidon Aqua 2 is an event-ready, Ultrasonic Low Fog Generator. It continuously creates high-output, low-lying fog without the use of cryogenics, refrigeration plants, or dry ice. The advanced ultrasonic technology internally combined with traditional thermally-produced fog means that the ONLY expendables required are fog fluid, water, and electrical power. The rugged chassis is designed for heavy-duty applications such as touring and can endure the rigors of use in the most demanding of applications.
With a simple, user-friendly LCD display, intuitive controls, and DMX onboard, the Poseidon Ultrasonic Low Fog Generator is ideal for any professional production, touring, themed entertainment, or theatrical application requiring voluminous low fog production that is quiet, efficient, and cost-effective.
Features:
- Advanced auto water refill system
- Multi-Stage humidity control
- Complete fog and fan volume control
- Optimized heater core for continuous operation
- Touch screen LCD & DMX control
Specifications:
AC Power:
- Input voltage & rate: 100-120 V - 50/60 Hz
- Wattage: 1700 Watts
- Heating: 4 minutes to heat up
Atomizers:
- Total power consumption: 500 Watts
- Unit Quantity: 2
- Power of each unit: 250 Watts
Capacity:
- Fog fluid tank capacity: 0.8 Gal
- Water chamber capacity: 6 Gal
Output:
- Volume adjustment range: 1-100
- Fog fluid consumption @ full volume: 25.0 mL/min
- Water consumption @ full volume: 240.0 mL/min
- Maximum continuous duration @ full volume: unlimited
Control:
- On-device manual control: LCD control board
- Wired control: DMX
- Control protocol: DMX-512
- DMX channel range: 3
- Data connectors: 3 and 5 -pin XLR
- Weight: 71 lbs.
- Dimensions: 29 x 15.5 x 17.7in
