Hubbell Straight Blade Single Receptacle, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R - Red

Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Red, Single Pack

• One-piece brass integral ground strap
• Unique bypass contact design
• Standard Product

General:

• Application: Heavy Duty Industrial
• Color: Red
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Horsepower - Maximum: 2
• Item Type: Single
• Material - Mounting Hardware: Screw Mounting
• Number Of Poles: 2-Pole
• OEM Brand Name: Hubbell Wiring Device-Kellems
• Operating Temperature: Maximum continuous 75°C and minimum -40°C without Impact
• Series: Extra Heavy Duty
• Style: Finder Groove Face
• Type: Single Receptacle
• UPC: 783585148786

Performance:

• Electrical - Current Interrupting - Certified for current interrupting at full rated current
• Electrical - Dielectric Voltage - Withstands 2,000V minimum
• Environmental - Flammability - Top: UL 94V-2, Base: UL 94V-0
• Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact)
• Mechanical - Product Identification - Ratings are a permanent part of the device
• Mechanical - Terminal Accommodation - #12-#10 AWG copper stranded or solid conductor only
• Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA

Dimensions:

• Dimensions: 3.28 in x 1.63 in x 1.19 in
• Display Size: Standard Sized Product
• Height: 1.19 in
• Length: 3.28 in
• Weight: 0.15 lb
• Width: 1.63 in

Electrical Ratings:

• Amperage Rating: 20 A
• Connectivity: Back and Side Wired Screw Terminals
• Current / Amperage Rating: 20 A
• Current Rating: 20 A
• Dielectric Strength: Withstands 2,000V minimum
• Phase: Single Phase
• Voltage Rating: 250 V
• Voltage Rating Description: 250 V
• Wattage: 5000 W

Conductor Related:

• Number Of Wires: 3-Wire
• Wire Size: #12 AWG to #10 AWG

Certifications and Compliance:

• Certified to CSA 22.2, No. 42 File 285
• Guide RTRT Fed Spec WC596G
• NEMA® WD-6 Compliant
• UL Listed to UL498 File No. E2186
• Nema Rating: 6-20R
• Standards - RoHS Compliance Status: CM

Logistics:

• Carton Quantity: 10
