Lex 20A Quad Box to (2) 5-20 Duplex Receptacles w/ Threaded Insert

This is an extremely versatile box for placing convenient (NEMA 5-20) receptacles exactly where you need them. The powerCON® connectors are compact and economical. With different length extensions you can create your own receptacle stringers. It also allows Edison (NEMA 5-15) equipped gear to be plugged into powerCON® distribution systems. The optional threaded insert allows the rubber quad box to be suspended from battens, truss or other structures.

Specifications:

• Rating: 20A 120 VAC
• Environmental Rating: TYPE 1 Indoor Use
• Input:
  • DB20PC-SBPC: (1) Neutrik® powerCON® blue device
  • DB20T1-SBPC: (1) Neutrik® powerCON® TRUE1 Inlet
• Output: (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 125 VAC duplex receptacles
• Feed Thru:
  • DB20PC-SBPC: (1) Neutrik® powerCON®grey device
  • DB20T1-SBPC: (1) Neutrik® powerCON® TRUE1 Outlet
• Enclosure: Rubber Quad Box
• Dimensions: 4.70”L x 2.50”W x 4.20”H
• Weight: 1.5 lbs.
