Light Source 10in. Mega Beam Clamp - 3 Ton - Black Anodized - Light Source MBC3T-10B
Details
The Mega-Beam Clamp is a low profile sliding jaw design that allows you to secure your load as close to the I-Beam as possible. The 10" model has a 3 ton rating. The two aircraft aluminum jaws are adjusted on the 3/4"-6" tip Acme threaded shaft. The spring loaded handle locks after adjustment. Aluminum construction is half the weight of steel units and has a wider gripping range.
Quick_Reference_Guide_4394_File_1.pdf
Fastens from 2 inch to 10 inch wide I-Beam flanges up to 1" thick. Center hole is 1-1/2"
Specifications:
- Safe Vertical Working Load: 6,000 lbs
- Weight: 10 lbs
