LumenRadio MoonLite Wireless CRMX Receiver and Transmitter - TiMoTwo Module

MoonLite^TM is a brand new patent-pending wireless lighting control product with LumenRadio’s updated award winning ultra-reliable CRMX technology combined with Bluetooth connectivity and a built-in battery.

By being a wireless DMX transmitter and receiver, MoonLite^TM is truly the Swiss army knife of the wireless DMX world!

Details:

MoonLite™ is built on LumenRadio’s patented reliable CRMX technology and boasts new features such as:

• Bluetooth connectivity
• Control and configure your Moonlight through the CRMX toolbox app
• Smarter disturbance detection technology, allowing for even more stable connectivity
• Significantly reduced RF footprint with dynamic transmissions

With built-in support for Bluetooth connectivity, MoonLite™ enables tablet and phone-based lighting control software to connect directly without the need for extra hardware. MoonLite™ is a state-of-the-art transceiver; thanks to its small size, built-in battery, and dual XLR connectors it is ideal for use at clubs, small stage events, corporate events, in theaters, and temporary events where wireless DMX connectivity is needed.

MoonLite™ has the same reliable functionalities as all LumenRadio’s CRMX products, but is updated with even smarter disturbance detection technology, allowing for even more stable connectivity – and it comes in a much smaller package.

Features:

• Built on the latest CRMX technology
• DMX transceiver (TX and RX)
• DC power
• Bluetooth connectivity
• Rechargeable battery included (10-12 hours in CRMX RX and 20 hours in Bluetooth mode)
• Check battery status through app
• Color coded pairing indication
• Velcro fastening
• Firmware updates available over Bluetooth, USB or XLR

Specifications:

• Supported Protocols:
  • USITT DMX512, DMX512(1990) & DMX512-A
  • Bluetooth 5.0
• RF Characteristics:
  • Operational frequency range:
  • 2402-2480 MHz
  • Output power levels:
  • 10dBm, 14dBm, 18dBm, 20dBm, 22dBm (only in US), 24dBm (only in US)
• Connectors:
  • DMX: 2 XLR, 5-pin gold plated, female and male
  • Antenna: Internal
  • DC: USB Micro-B
• Power:
  • Low voltage input: 5VDC
