NovaStar VX600 All-In-1 Controller

(0)No Reviews yet
SKU: NovaStar VX600


The VX600 is NovaStar's new all-in-one controller that integrates video processing and video control into one box. It features 6 Ethernet ports and supports video controller, fiber converter and Bypass working modes. A VX600 unit can drive up to 3.9 million pixels, with the maximum output width and height up to 10,240 pixels and 8192 pixels respectively, which is ideal for ultra-wide and ultra-high LED screens.

Highly Versatile:

The VX600 is capable of receiving a variety of video signals and processing high-resolution images. In addition, the device features stepless output scaling, low latency, pixel-level brightness and chroma calibration and more, to present you with an excellent image display experience.

Tech Specs
Controller & Processor:

The VX600 is a 6-port 2-in-1 video controller that combines video processing and video control functions. It can be widely used in the field of medium to high-end rental, stage control systems and fine-pitch LED screens.


  • LCD menu display
  • Intuitive display interface
  • PC: Ethernet, USB (A/B), Genlock IN + LOOP

Power & Current:

  • 100-240VAC, 50-60 Hz
  • Power consumption: 28W, 1.5A


  • 2" x 13.9" x 19"
  • 8.9lbs

General Specs:

  • Loading capacity: 3.9m pixels
  • Layers: 3
  • Mosaic input source supported
  • Audio input and output
  • 3D functions
  • Low latency
  • Output synchronization


  • 2x HDMI 1.3 + LOOP In
  • 2x DVI (HDMI 1.3) + LOOP In
  • 1x 3G-SDI + LOOP In
  • 6x Gigabit Ethernet outputs
  • 1x 10G OPT port
  • 1x HDMI 1.3 (monitor)
  • 1x RJ45 Ethernet (PC)
  • 1x USB Type A (cascading)
  • 1x USB Type B (PC)
  • 1x Genlock In + LOOP


  • 3 Year
