Pathway Front Connector Kit for Quattro - 2-XLR5M Input & 2-XLR5F Output

Front connector kit for the Pathway Pathport Quattro, with 2 male 5-pin XLR inputs and 2 female 5-pin XLR outputs.

Note on Front Connector Kits:
The use of the front connector kit with a Quattro requires the full width of 1RU of rack space (so it is not possible to have two Quattros side-by-side and use the adaptor kit). The adaptor kit is typically used with the 6312 model.

Features:

• Four DMX512 ports, individually configurable
• IP, subnet mask, port direction, protocol receive/send, basic patching - and more - all settable from the front panel
• 8-way DMX routing per port, including priority and merge on a chanel-by-channel basis, available with use of free Pathport Manager 5 configuration software
• RDM gateway, in conjunction with Pathport Manager 5
• Simple, reliable firmware upgrade process
• DMX output speed and signal loss behavior user-set
• Normal operation uses Power-over-Ethernet (Class 2, 8W maximum)
• When PoE is not available, may operate from an auxiliary 24VDC input (by others)
Rack ears included
• Truss and wall mount kits available as accessories
• Multiple connector styles including: XLR5, XLR3, terminal block and RJ45 EtherCon
