Pliant Technologies CRP-12-2400

Designed to work specifically with CrewCom's CB2-2400 BaseStation, the CRP-12-2400 wireless beltpack employs a frequency range of 150 Hz to 7 kHz to deliver high-quality speech transmission.

Full duplex operation (transmission in two directions simultaneously) allows you to carry on conversations as you would in-person. Plus, it allows users to independently listen and talk on two conferences.

The CRP-12-2400 operates at 2.4GHz which delivers a range of approximately 300 meters (900'). The radio pack's lightweight design, advanced RF technology, and backlit LED channel indicator make the CRP-12-900 an extremely user-friendly option.

(Note: This Radio Pack is ONLY compatible with the CB2-2400 BaseStation, is NOT compatible with any CrewCom CCU-44 or CCU-22 CU.)


Includes:

• Radio Pack
• Lithium-Polymer Rechargeable Battery
• Battery Charger / Power Supply
• USB A to Micro B cable
• Quick Start Guide

Features:

• Compact size
• Light weight (13 oz./ 369 g)
• 7 kHz audio for excellent voice quality
• Familiar volume/talk user interface
• Preprogrammed Function Buttons (x2)
• USB connection for pairing, firmware updates and battery charging
• Dual battery (Li-Poly or AA) operation
• Greater than 9 hours continuous operation (Li-Poly)
• Easy-to-use spring-loaded belt clip

Specifications:

• RF Frequency (MHz): 2400–2483 MHz
• RF Scheme: FHSS with TDMA
• Effective Radiated Power: 100 mW (+20 dBm)
• Receiver Sensitivity: -100 dBm at 10-5 BER
• Radio Certification: FCCID: HSW-CCT24 and IC: 4492A-CCT24
• Transmission Range :150 m (approx. 500 ft.) under typical conditions; 450 m (approx. 1500 ft.) line of sight (Note: Functional range depends on many variables, including RF signal absorption, reflection, and external interference.)
• Audio Dynamic Range: Greater than 90 dB
• Audio Frequency Response: 150 Hz–7 kHz
• Channels: 2
• Volume Knobs: 1
• Talk Buttons: 1
• Headset Connector: 4-pin male XLR
• Microphone Type: Auto Detect; Dynamic or Electret
• Antenna: (2) 2dBi Dipole
• Battery Life, Rechargeable Lithium-Polymer: Greater than 10 hours
• Charging Power Supply: Micro USB; 6W AC wall adapter
• Charge Time for Lithium-Polymer Battery (with supplied PSU): Under 3 hours Optional Power: 3 Standard AA alkaline batteries
• Battery Life, AA Batteries: Approximately 5 hours Dimensions
• (L x W x H): 11.43 cm × 11.61 cm × 5.87 cm (4.50 in. × 4.57 in. × 2.31 in.) Weight: (with Lithium-Polymer battery) 350 g (12.3 oz.)
• Material: Polycarbonate substrate with thermoplastic elastomer overmold Operating Environment: -20° to 50° C (-4° to 122° F); 10% to 90% Humidity. RP Power Supply is 0 to 40° C (32° to 104° F).
• Maximum Altitude: 2,000 m (6,562 ft.)
• RoHS Compliant: Yes
• IP Rating: IP-65
• Compliance Model Number: RP2500
